─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

89 Hex Head Bolt M10*35 2 127 Weight Plate 15LBS 10

90 Hex Head Bolt M10*30 10 128 Plastic Cap Φ30 2

91 Hex Head Bolt M10*25 5 129 Washer Φ27.6*Φ12.8*3.5 2

92 Button Head Cap Screw M8*60 1 130 Nut 2

93 Button Head Cap Screw M8*55 1 131 Pin End Φ17.7*50 1

94 Flat Head Cap Screw M10*25 4 132 Spring Φ1.5*36 1

95 Flat Head Cap Screw M10*30 5 137 Rubber Plug Φ29*Φ19*10 2

96 Flat Head Cap Screw M10*75 1 138 Hex Head Bolt M8*30 2

97 Socket Set Screw 10-32*6.4 2 139 Spring Washer Φ8 2

98 Socket Head Cap Screw M8*30 1 140 Flat Washer Φ9*Φ22*1.6 2

99 Socket Head Cap Screw M8*15 2 141 Rivet Nut M8 2

100 Socket Head Cap Screw M8*25 4 147 Socket Set Screw M6*15 2

101 Socket Head Cap Screw M5*25 2 148 Baffle Plate 1

102 Flat Philips Screw M5*25 2 149 Hex Head Bolt M8*15 2

103 Flat Philips Screw M5*16 4 151 Hex Head Bolt M10*75 2

104 Button Head Cap Screw M6*12 2 152 Rivet Nut M10*19.5 3

105 Socket Set Screw 10-32*3.2 4 153 Hex Head Bolt M12*65 3

106 Hex Nut M6 18 154 Screw M5*12 9

107 Nylon lock Nut M12 6 155 Rivet Nut M5 5

108 Nylon lock Nut M10 2 156 Shroud Clip 12

109 Nylon lock Nut M8 11 157 Plastic Cover 1

110 Nylon lock Nut M5 49 158 4.5" Pulley for Sensor 1

111 Flat Washer Φ13*Φ24*1.5 10 159 Plate for Sensor 1

112 Flat Washer Φ11*Φ20*2 4 160 Philips Screw M3*8 4

113 Flat Washer Φ9*Φ16*1.6 10 161 Sensor 2

114 Flat Washer Φ5.5*Φ12*1 4 162 Console PCB 1

116 Hex Key S=3 1 164 Screw ST2.9*9.5 2

117 Hex Key S=4 1 165 Cover for Magnetic Iron 1

118 Hex Key S=5 1 166 Magnetic Iron 2

119 Hex Key S=6 1 167 Top Front Shroud 1

121 Hex Key S=3/32" 1 168 Support 1

122 Wrench 1 169 Top Cover 1

123 Lube 1 170 Left Plug 1

125 Weight Plate 5LBS 2 171 Right Plug 1

126 Weight Plate 10LBS 3 172 Hex Head Bolt M10*55 3
