Assembly

STEP 2

1. Attach the Pivot Axle Φ25*364 (#19) to the Bottom Cross Brace (#2) using:

● one D=25 Retaining Snap Ring (#68) ●

one M10*25 HHB (#84)

● one Φ11*Φ20*2 Flat Washer (#71)

2. Attach the Pivot Axle Φ25*449 (#18) to the Bottom Cross Brace (#2) using:

● one D=25 Retaining Snap Ring (#68) ● one M10*25 HHB (#84)

● one Φ11*Φ20*2 Flat Washer (#71)

3. Attach the Adjustable Cam (#9) and the Cam Support Tube (#10) to the Pivot Axle

Φ25*449 (#18) using:

● Φ Φ ●

one D=25 Retaining Snap Ring (#68)

two 32* 26*5 Washers (#32)

Φ Φ

●

one 13* 24*1.5 Flat Washers (#69)

one 55* 12.2*5 Big Washer (#25)

● one M12*25 HHB (#87)

4. Attach the Cover (#16) to the Bottom Cross Brace (#2) using:

● two M10*15 HHB (#83) ● two Φ11*Φ20*2 Flat Washers (#71)

Note: Hand tighten Bolts and Nylon Lock nuts.

STEP 3

1. Insert the Left Leg Arm (#6) and the Right Leg Arm (#5) to the Φ25*364 Pivot

Axle (#19) and the Φ25*449 Pivot Axle (#18), then attach the Pivot Actuator Plate

(#14) to the Left Leg Arm (#6) and the Right Leg Arm (#5) using:

● two Φ11*Φ20*2 Flat Washers (#71) ● two M10 Nylon lock Nuts (#94)

2. Attach the Pivot Axle Support Tube (#7) to the Φ25*364 Pivot Axle (#19) and the

Φ25*449 Pivot Axle (#18) using:

● two M10*25 HHB (#84) ● two Φ11*Φ20*2 Flat Washers (#71)

3. Attach the Connect Tube (#4) to the Pivot Axle Support Tube (#7) and the Rear

Frame (#3) using:

● two M10*75 HHB (#80) ● two M10*80 HHB (#81)

● eitht Φ11*Φ20*2 Flat Washers (#71) ● four M10 Nylon lock Nuts (#94)

4. Attach the Handle (#8) to the Connect Tube (#4) using:

● two M10*75 FHCS (#75) ● two M10*80 HHB (#81)

● six Φ11*Φ20*2 Flat Washers (#71) ● four M10 Nylon lock Nuts (#94)

Note: Wrench Tighten Bolts and Nylon Lock nuts.

5. Attach four □50 Plugs (#61) to the Bottom Cross Brace (#2) and the Pivot Axle

Support Tube (#7).
