Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

66 Hex Head Bolt M10*30 8 102 Hex Head Bolt M10*80 2

67 Hex Head Bolt M10*25 4 103 Aluminium Cap Φ38*Φ10.5*8 2

68 Button Head Cap Screw M8*55 1 104 Flat Head Cap Screw M10*25 9

69 Hex Head Bolt M10*45 1 105 Aluminium Grip Cap 2

70 Hex Head Bolt M12*40 2 106 Cable End 1

71 Socket Head Cap Screw M10*50 5 107 Spacer Φ10*Φ14*20 1

72 Socket Head Cap Screw M8*30 1 109 Nut 2

73 Socket Head Cap Screw M16*40 4 110 Cushion 1

74 Button Head Cap Screw M6*12 2 114 Tapped Hole Nut M8 2

76 Flat Head Cap Screw M10*30 4 115 Rubber Plug Φ29*Φ19*10 2

79 Flat Washer Φ13*Φ24*1.5 2 116 Spring Washer Φ8 2

80 Flat Washer Φ11*Φ20*2 41 119 Flat Washer Φ9*Φ22*1.6 2

81 Flat Washer Φ9*Φ16*1.6 2 125 Socket Set Screw M6*15 2

82 Hex Nut M6 2 126 Hex Key s=3 1

83 Hex Nut M16 2 127 Philips Screw M5*12 9

84 Nylon lock Nut M8 2 128 Rivet Nut M5 5

85 Nylon lock Nut M10 20 129 Hex Head Bolt M10*75 2

86 Nylon lock Nut M12 2 130 Shroud Clip 12

87 Socket Set Screw 10-32*3.2 4 131 Plastic Cover 1

90 Hex Key s=5 1 132 4.5" Pulley for Sensor 1

91 Hex Key s=6 1 133 Plate for Sensor 1

92 Hex Key s=8 1 134 Philips Screw M3*8 4

93 Hex Key s=12 1 135 Sensor 2

94 Hex Key s=3/32" 1 136 Console PCB 1

95 Wrench 1 137 Cover for Magnetic Iron 1

96 Lube 1 138 Magnetic Iron 2

98 Tie Rod End M16*Φ16 (Left) 2 139 Screw ST2.9*9.5 2

99 Hex Nut M16 (Left) 2 140 Hex Head Bolt M10*55 1

101 Hex Key s=4 1
