Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 30 Bit Washer Φ50*Φ10.5*8 2

2 Main Frame 1 31 Aluminium Grip Cap 1

3 Bottom Cross Brace 1 32 Aluminium Grip Ring 3

4 Rear Cross Brace 1 33 Aluminium Cap Φ50*M16*8 2

5 Lat Arm 2 34 Tie Rod End M16 2

6 Lat Bar 2 35 Bearing Φ42*Φ20*12 2

7 Chest Adjustable Tube 1 36 Taper Bearing Φ37*Φ20*12 2

8 Chest Pad Support 1 37 Bearing Φ50.8*Φ25.4*15.9 4

9 Seat Pad Support 1 38 Bushing 2

10 Mobile Frame 1 39 Spacer Φ10*Φ14*20 2

11 Adjustable Foot plate 4 40 Spring 2

12 Top Plate 1 41 Pulley Cover Φ114*24 12

13 Adjustable Support 2 42 Button 19

14 Selector Pin W/Coil 1 47 Top Front Shroud 1

16 3.5" Pulley 8 53 Plastic Tube Guide 4

17 Guide Rod 2 54 Weight Rubber Bumper Φ63.5*Φ19*25.4 2

18 Screw Shaft 2 55 Rubber Plug Φ29*Φ19*10 2

19 Pivot Axle A Φ25.4*Φ12.2*92 2 56 Elliptical Rubber Bumper 4

20 Cable_1 1 57 Grip DTΦ32*Φ24*285 2

21 Cable_2 1 58 Grip STΦ30*Φ22*120 1

23 Chest Pad 1 59 Adjustable Support Sleeve 2

24 Seat Pad 1 60 Flat Head Cap Screw M10*30 3

25 Washer Φ23*Φ16.4*3 4 61 Flat Head Cap Screw M8*20 6

26 Pivot Axle Φ16*42 2 62 Flat Washer Φ28*Φ10.5*5 4

27 Nut 25*2.5*21.6 1 63 Flat Washer Φ13*Φ24*1.5 6

28 Cable End Φ25.4*Φ10*37 2 64 Hex Head Bolt M8*30 2

29 Foot Pad 2 65 Flat Washer Φ11*Φ20*2 28
