Aerofit IE9519 [6/23] 页面 6

Превью страниц Страница 6 / 23

─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

66 Flat Washer Φ9*Φ16*1.6 4 96 Hex Key s=5 1

67 Nylon Lock Nut M10 19 97 Hex Key s=6 1

68 Nylon Lock Nut M12 3 98 Hex Key s=8 1

69 Nylon Lock Nut M8 2 99 Wrench 1

70 Rivet Nut M8 8 100 Lube 1

71 Hex Nut M16 2 105 Front Shroud 1

72 Hex Nut M6 4 109 Rear Shroud 1

73 Hex Head Bolt M10*100 2 112 Spring Washer Φ8 2

74 Hex Head Bolt M10*135 2 121 Socket Set Screw M6*15 4

75 Hex Head Bolt M10*75 2 122 Hex Key s=3 1

76 Flat Washer Φ9*Φ22*1.6 2 125 Support 1

77 Hex Head Bolt M10*30 4 126 Top Shroud 1

78 Hex Head Bolt M10*35 2 127 Left Plug 1

79 Hex Head Bolt M10*50 4 128 Right Plug 1

80 Hex Head Bolt M10*65 2 130 Screw M5*12 9

81 Hex Head Bolt M12*120 2 131 Rivet Nut M5 5

82 Hex Head Bolt M12*85 1 132 Hex Head Bolt M10*55 1

83 Socket Head Cap Screw M10*50 6 133 Shroud clip 12

84 Socket Head Cap Screw M8*30 2 134 Plastic Cover 1

86 Retaining Snap Ring 2 135 4.5" Pulley for Sensor 1

88 Button Head Cap Screw M6*12 4 136 Plate for sensor 1

89 Button Head Cap Screw M8*55 2 137 Philips Screw M3*8 4

90 Socket Set Screw 10-32*3.2 6 138 Sensor 2

91 Cable Connector 1 139 Console PCB 1

92 Hex Flanged Nut 1/2"-13 1 140 Cover for Magnetic Iron 1

93 Hex Key s=3/16" 1 141 Magnetic Iron 2

94 Hex Key s=3/32" 1 142 Screw ST2.9*9.5 2

95 Hex Key s=4 1
