─ 5 ─
Parts List
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.
ITEM NO.
Description QTY
ITEM NO.
Description QTY
1 Weight Stack Frame 1
45 Flat Washer Φ9*Φ22*1.6 2
2 Seated Frame 1
46 Flat Washer Φ11*Φ20*2 55
3 Front Frame 1
47 Nylon Lock Nut M10 22
4 Foam Support Frame 1
48 Nylon Lock Nut M8 1
5 Pop Pin 1
49 Flat Head Cap Screw M10*30 4
6 Support Frame 1
50 Hex Nut M10 1
7 Top Frame 1
51 Hex Nut M6 2
8 U Bracket 2
52 Hex Head Bolt M10*100 2
9 Foot tube 1
53 Hex Head Bolt M10*50 6
10 Cover Plate 1
54 Hex Head Bolt M10*65 2
11 Pulley Bracket 1
55 Hex Head Bolt M10*70 4
12 Cable 1 1
56 Hex Head Bolt M10*75 8
13 Cable 2 1
57 Hex Head Bolt M10*20 2
14 Seat Pad 1
58 Hex Head Bolt M8*30 2
15 Short Foam 2
59 Hex Head Bolt M10*30 4
16 Adjustable Foot plate 4
60 Hex Head Bolt M10*35 2
17 Top Plate 1
61 Socket Head Cap Screw M8*30 1
18 4.5" Pulley 7
62 Socket Set Screw M8*8 2
19 Selector Pin W/Coil 1
63 Philips Screw M5*12 5
20 Long Lat Bar 1
64 Button Head Cap Screw M6*12 2
21 Adjustable End 1
65 Hex Key s=3/16" 1
22 Lat Bar 1
66 Hex Key s=4 1
23 Gear Hook 2
67 Hex Key s=6 1
24 Foam Tube 1
68 Wrench 1
25 Guide Rod Φ19*1477 2
69 Lube 1
26 Support Hook(R) 1
70 Plastic Cover 1
27 Support Hook(L) 1
71 Hex Nut M8 2
28 Shot Chain 1
73 Rivet Nut M5 1
29 Bolt Φ9.4*47.5*M8 1
74 Spring Washer Φ8 2
30 Nut 25*2.5*21.6 2
75 Button 8
31 Aluminium Ring 4
76 Top Front Shroud 1
32 Bit Washer Φ60*Φ10.5*10.9 2
77 Rear Shroud 1
33 Aluminium Grip Cap 2
78 Left Plug 1
34 Bushing Φ12.7*Φ9.5*9.5 2
79 Right Plug 1
35 Adjustable Stopper 1
88 Shroud Clip 16
40 Plastic Tube Guide 2
91 Rubber Plug Φ29*Φ19*10 2
41 Weight Rubber Bumper 2
100 3"Pulley 1
42 Foot Sleeve 2
101 2"Pulley 1
43 Plug RT50*100 1
110 Front Shroud 1
44 PU Antiskid 1
