Yamaha EZ-150 [14/68] Step 2 songs
![Yamaha EZ-150 [14/68] Step 2 songs](/views2/1013573/page14/bge.png)
14
Quick
Guide
Step 2
Songs
01
xwz
zxc
q
Playing the Songs
The EZ-150 is packed with 100 songs, including 10 special Demo songs.
Demo songs (01 - 10) showcase the sophisticated features
and stunning sound of the EZ-150. Let’s play the Demo
songs now, starting with 01...
z
Press the [DEMO] button.
x
Stop the Demo song.
You can also play back songs of other categories. Simply
select the appropriate number of the desired song during
playback.
Playing the Demo songs
• Demo Cancel function that allows you to disable the Demo feature. To
use this, simultaneously hold down the [DEMO] button and turn the
power on ([STANDBY/ON] button). While the power is on in this condi-
tion, pressing the [DEMO] button has no effect. To turn Demo Cancel
off, simply turn the power off and back on again normally.
-1
or
Naturally, you can also individually select and play back
any of the EZ-150 songs (00 - 99).
z
Press the [SONG] button.
x
Select a song.
c
Start (and stop) the song.
Want to find out more? See page 31.
Playing a single song
01
06
