55
Voice List
The following voices can be selected when the Voice mode is active, or when the Voice Change function is on.
They can also be selected by a connected MIDI device; the corresponding bank select messages are: MSB = 00H,
LSB = 70H.
When selecting voices via MIDI:
* The Harmony voices (#59 - #68) and Echo voices (#79 - #88) are sounded without the respective harmony and
echo effects.
● Panel Voice List
*1 MSB=7FH, LSB=00H, Prg Ch#=1
*2 MSB=7FH, LSB=00H, Prg Ch#=2
Voice
No.
MIDI Program
Change No.
Voice Name
Used
Notes
PIANO
01 0 GRAND PIANO 2
02 1 HONKY-TONK PIANO 2
03 2 ELECTRIC PIANO 1 2
04 3 ELECTRIC PIANO 2 2
05 4 ELECTRIC PIANO 3 2
06 5 ELECTRIC PIANO 4 2
07 6 HARPSICHORD 2
08 7 CLAVI 1
09 8 CELESTA 1
ORGAN
10 9 VIBRATO OFF 2
11 10 VIBRATO ON 2
12 11 HARMONY OFF 2
13 12 HARMONY ON 2
14 13 ATTACK OFF 2
15 14 ATTACK ON 2
16 15 WAVE OFF 2
17 16 WAVE ON 2
18 17 PIPE OGAN 2
19 18 ACCORDION 2
20 19 HARMONICA 1
GUITAR/BASS
21 20 SOFT GUITAR 1
22 21 FOLK GUITAR 1
23 22 12STRINGS GUITAR 2
24 23 JAZZ GUITAR 1
25 24 ELECTRIC GUITAR 2
26 25 DISTORTION GUITAR 2
27 26 WOOD BASS 1
28 27 FINGER BASS 1
29 28 SLAP BASS 1
STRINGS/MALLET
30 29 STRINGS 1
31 30 VIOLIN 1
32 31 CELLO 1
33 32 HARP 1
34 33 SITAR 1
35 34 BANJO 1
36 35 VIBRAPHONE 1
37 36 MARIMBA 1
38 37 STEEL DRUMS 1
WIND
39 38 TRUMPET 1
40 39 TROMBONE 1
41 40 MUTE TRUMPET 1
42 41 FRENCH HORN 1
43 42 BRASS SECTION 1
44 43 ALTO SAX 1
45 44 TENOR SAX 1
46 45 OBOE 1
47 46 CLARINET 1
48 47 FLUTE 1
49 48 PAN FLUTE 1
SYNTHESIZER
50 49 THICK LEAD 2
51 50 SIMPLE LEAD 1
52 51 THICK SAWTOOTH 2
53 52 SIMPLE SAWTOOTH 1
54 53 SYNTH BASS 1
55 54 SYNTH STRINGS 1
56 55 SYNTH BRASS 2
57 56 SLOW STRINGS 1
58 57 CHORUS 1
HARMONY
59 58 PIANO TRIO 3
60 59 PIANO COUNTRY 2
61 60 ELECTRIC PIANO TRIO 3
62 61 HARPSICHORD TRIO 3
63 62 ELECTRIC ORGAN TRIO 3
64 63 VIBRAPHONE DUET 2
65 64 TRUMPET DUET 2
66 65 HORN DUET 2
67 66 CLARINET TRIO 3
68 67 FLUTE DUET 2
SPLIT
69 68 WOOD BASS / PIANO 1
70 69 STRINGS / PIANO 1
71 70 FINGER BASS / ELECTRIC PIANO 1
72 71 HARP / VIOLIN 1
73 72 FRENCH HORN / TRUMPET 1
SUSTAIN
74 73 SUSTAIN PIANO 1
75 74 SUSTAIN ELECTRIC PIANO 1 1
76 75 SUSTAIN ELECTRIC PIANO 2 1
77 76 SUS VIBRAPHONE 1
78 77 SUSTAIN STRINGS 1
ECHO
79 78 ECHO PIANO 1
80 79 ECHO ELECTRIC PIANO 1
81 80 ECHO HARPSICHORD 1
82 81 ECHO CELESTA 1
83 82 ECHO FOLK GUITAR 1
84 83 ECHO BANJO 1
85 84 ECHO VIBRAPHONE 1
86 85 ECHO MARIMBA 1
87 86 ECHO STEEL DRUMS 1
88 *1 ECHO DRUM KIT 1
DUAL
89 88 PIANO CONCERTO 2
90 89 ELECTRIC PIANO CONCERTO 2
91 90 FAIRY LAND 2
92 91 MOOD GUITAR 2
93 92 RICH GUITAR 2
94 93 HOT ORGAN 2
95 94 EXCEL VIOLIN 2
96 95 CRYSTAL 2
97 96 STAR SHIP 2
DJ Voice
98 97 DJ VOICE 1 1
99 98 DJ VOICE 2 1
DRUMS
00 *2 DRUM KIT 1
Voice
No.
MIDI Program
Change No.
Voice Name
Used
Notes
