Selecting and Playing Styles
49
Adjusting the Accompaniment Volume
The playback volume of the accompaniment can be adjusted. This volume con-
trol affects only the style volume. The volume range is 00 - 99.
1 Select the Accompaniment Volume function in the Overall
menu.
Press the [OVERALL] button, repeatedly if necessary, until “o7” appears in
the display.
2 Change the value.
Use the numeric keypad to set the desired Accompaniment Volume value (00
- 99). You can also use the [+]/[–] buttons to increase or decrease the value.
Holding down either button continuously increases or decreases the value.
About the Fill-in Patterns
1234123412341233
...a fill-in pattern
plays from here...
...and the Main
A or B section
begins here.
If you press the
[MAIN/AUTO FILL]
button here, after
beat 4...
...a fill-in pattern
plays immediately
until the end of the
measure...
...and the Main A
or B section
begins here.
If you press the
[MAIN/AUTO FILL]
button before beat
4...
beat
1st measure 2nd measure 3rd measure
o7
• Accompaniment Volume cannot
be changed unless the Style
mode is active.
Resetting the Accompaniment
Volume Value
If you’ve changed the Accompani-
ment Volume setting, you can
instantly restore the default setting
of “90” by pressing both [+]/[–] but-
tons simultaneously (when Accom-
paniment Volume is selected).
