14
1 Symbols
Warning of general danger
Risk of electric shock
Wear ear protection.
Wear a dust mask!
Read the operating instructions/notes
2 Technical data
Cutting depth at 90°/45° 0 - 70 mm/ 0 - 48 mm
Inclination -2° - 47°
Max. cutting length 330 mm
Saw blade 225 x 30 x 2.5 mm
Idling speed
CS 70 EB, adjustable 2000 - 4200 rpm
CS 70 E 4200 rpm
Power consumption 2,200 W
Table dimensions (L x W) 690 x 500 mm
Bench height with foldaway legs 900 mm
Bench height without
foldaway legs 375 mm
Weight with foldaway legs 34 kg
Protection category of motor (CS 70 EB only)
and IP5X switch according to EN 60529.
Bench-mounted circular saw and circular
trimming saw
PRECISIO CS 70 E, CS 70 EB
The specifi ed illustrations are at the beginning of
this operating manual.
3 Machine features
[1-1] Foldaway legs
[1-2] On/off switch
[1-3] Cable holder
[1-4] Table insert
[1-5] Rotary knob for adjusting the fence
[1-6] Spacer wedge
[1-7] Stop lever
[1-8] Cutting depth adjuster
[1-9] End cap
[1-10] Groove
[1-11] Rotary knob for adjusting the protective
cover
[1-12] Knobs for adjusting the foldaway legs
4 Intended use
The PRECISIO is designed as a transportable
electric power tool for sawing wood, plastics,
panel materials made of wood and similar mate-
rials. Special aluminium cutting blades supplied
by Festool allow you to use these machines to
saw aluminium. Materials containing asbestos
must not be processed.
The user bears the responsibility for damage and
accidents caused by improper use.
5 Safety instructions
WARNING! Read all safety warnings and
all instructions. Failure to follow the warn-
ings and instructions may result in electric shock,
fi re and/or serious injury.
Save all warnings and instructions for future
reference.
Never allow children to use the machine. -
Before using the machine, make yourself suf- -
fi ciently familiar with the application, setting
and operation of the machine.
5.1 Machine-related safety instructions
Deformed or cracked saw blades and saw -
blades with blunt or broken cutting edges
must not be used.
The maximum rotational speed specifi ed on -
the tool must be observed.
The tool must be compatible with the working -
material.
