Panasonic ER230 [4/63] Operation

M Adaptor

Use this to connect the trimmer

to an AC power source for re-

charging or for AC operation.

N Oil

Lubricate the space between the

stationary and moving blade with

2 or 3 drops of oil after use. (see

fig. 16)

O Cleaning Brush

READ ALL INSTRUCTIONS BE-

FORE USE.

Operation

Charging and cordless trimming

When charging the beard/hair trim-

mer for the first time or when it has

not been in use for more than 6

months, charge it for the activation

for at least 16 hours before use.

Connect the power cord to the beard/

hair trimmer, and plug the adaptor to

an AC outlet.

In some areas, a special plug adap-

tor may be required.

The charge indicator lamp will glow

red and it will stay on until the adap-

tor is disconnected from the AC out-

let. (see fig. 4)

You can fully charge the trimmer in 8

hours if it seems to be losing speed.

A full charge will supply enough

power for approx. 10 trims (5 minutes

per trim for a normal beard).

AC operation

Connect the AC adaptor to the body

in the same way as for charging, and

set the switch to “1” to use the trim-

mer.

If the trimmer does not operate after

connection as mentioned above, re-

turn switch to “0•charge” position for

1 minute and then set switch back to

“1” position.

Trimming of beard

Place the angled face of the comb

against the skin and cut the beard

by moving the trimmer in all direc-

tions to obtain a uniform cut. (see fig.

With curly facial hair, the comb at-

tachment may not cut all of the hair.

In this case, remove the comb attach-

ment and use a conventional comb

to draw out the remaining uncut, hair.

(see fig. 6)

When shaping the beard, remove the

comb attachment. Place the angled

edge against the skin and make the

border of the beard even.

Thinning Plate

When thinning, slide the thinning

plate up until it firmly clicks in

position. (see fig. 7)

Thinning Plate Lock Button

Press and hold while sliding the

Thinning plate down to set the

Thinning Plate back to its original

position.

This Beard/Hair Trimmer is for the

trimming and care of mustaches,

beards and hair. Trimming length can

be adjusted between 1 to 20 mm. The

trimmer can be operated either from

an AC power source or on its own

rechargeable battery.

Parts identification

(see fig. 1)

A Switch

Slide up to turn on, slide down to

turn off.

B Charge Indicator Lamp

Lights when the unit is connected

with the adaptor to an AC

power source for charging.

C Main Blade

A precision 39 mm-wide blade

which can be used with the comb

attachment F

D Quick Adjust Dial

Turn the dial to a higher setting to

raise or lower the comb attach-

ment F to the desired length (be-

tween 1 and 20 mm) (see fig. 2).

The comb attachment is locked

in position when the switch is set

to “1”.

E Trimming Length Indicator

Indicator Trimming Length

1 1.0 mm

2 2.0 mm

• 3.5 mm

5 5.0 mm

• 6.5 mm

8 8.0 mm

• 9.5 mm

11 11.0 mm

• 12.5 mm

14 14.0 mm

• 15.5 mm

17 17.0 mm

• 18.5 mm

20 20.0 mm

• The actual hair length may be

longer than the set trimming length.

F Comb Attachment

Use this to control the trimming

length. (see fig. 3)

G Moving Blade

H Stationary Blade

I Cleaning Lever

Push this lever to remove bits of

hair caught between the station-

ary blade and the moving blade.

J Blade Block

Release to remove the blade

block from the housing to clean

or replace the blade. (see fig. 12)
