EDID Designer - Defining the EDID Designer
#
Feature
Function
12
Select All Checkbox
Check to select all inputs
13
Connection Status Icon
Shows if the input or output is connected or
disconnected
14
ADD Button
Click to add and specify a CEA Extension
15
Binary EDID Map
Displays the binary representation of the EDID being
viewed or edited. The highlighted bytes represent the
selected descriptor tab
16
Descriptor Tabs
Click each tab to open a list of descriptor-specific
parameters
17
SAVE Button
Click to save the changes to the source of the EDID being
edited (disk file or device)
18
DISCARD Button
Click to throw away all unsaved changes
19
EDID Title
Title of the EDID being edited
20
SIMPLIFIED Tab
Displays a shortened form of the EDID based on a
summary of commonly accessed functions
21
ADVANCED tab
Displays the full version of the EDID
22
Active EDID status
Displays the status of the EDID dragged to EDID Display
Panel (On Drag, On Edit, On View)
