EDID Designer - Editing an EDID
17
5.1 Using the Simplified Tab
The Simplified mode is used for easy editing of the frequently used EDID
properties. Since the EDID block structure includes many cross references
between data fields, the Simplified mode prevents the user from creating EDID
blocks that might cause signal compatibility issues and the application does NOT
alter the EDID data block structure.
This means that in the Simplified mode the application denies any editing actions
that might change the total size or order of the block. Adding or removing CEA
extensions is prohibited. To make changes to the structure of the EDID block, use
the Advanced mode.
Simplified mode rearranges the displayed data in convenient and logical groups
with shared functionality. This is in direct contrast to the advanced mode, where
the exact block structure and content is maintained and displayed as it appears in
the EDID.
