EDID Designer - Editing an EDID

5 Editing an EDID

EDID Designer allows the user to manipulate the full EDID, with all its parameters

and extensions using the Advanced tab (see Section 5.3). The Advanced tab is a

full representation of the EDID according the White Paper referenced in Section 1,

and uses the exact field names used in the EDID white paper.

The Simplified tab (see Section 5.1) provides a summary view of the EDID

showing the most frequently changed parameters based on the most commonly

used functions. The Simplified tab takes its information from the Advanced tab.

Changing any parameter changes the value in both tabs. Various logical operators

also try to ensure that certain combinations of parameters cause only valid options

to display for selection.

This guide does not provide a detailed explanation of all the EDID parameters.

The user must be familiar with EDID structure and the meanings of fields in the

descriptors and is referred to the White Paper for full explanations of the fields in

the EDID.
