Connecting the SP-12HD HD-SDI Processor

6 Connecting the SP-12HD HD-SDI Processor

You can use your SP-12HD to convert

composite video, s-Video,

component video (YUV), or SDI signals to composite video (PAL or

NTSC), s-Video, component video (YUV) and

Figure 2

SDI, as well as to a

“Before/after” split-screen, as the example illustrates in .

To connect

the SP-12HD Digital Video Processor, do the following

1. Connect the following sources to the SP-12HD:

• The composite video source (for example, a DVD player)

to the CV INPUT BNC connector

• The s-Video source (for example, an S-VHS player) to the

Y/C INPUT 4-pin connector

• The SDI source (for example, a digital video player) to the

SDI INPUT BNC connector

2. Connect the component video INPUTS BNC connectors, Y, B-Y, and

R-Y to YUV video source.

3. Connect the following acceptors to the SP-12HD:

• The SPLITTER OUTPUT BNC connector to the split

image acceptor (for example, a display)

• The Y/C OUTPUT 4-pin connector to an s-Video acceptor

(for example, a display)

• The CV OUTPUT BNC connector to a composite video

acceptor (for example, a display)

• The BNC OUTPUTS connectors: Y, B-Y and R-Y to a

video acceptor (for example, a plasma display)

• The two SDI OUTPUTS BNC connectors to two serial

digital video acceptors (for example, two monitors: SDI 1

and SDI 2)

4. Connect a PC or other controller, if required (see section

6.1).

5. Set the DIP-switches (see section

6.2).

6. Connect the AC power cord.

1 The SP-12HD does not perform standard conversion or scaling. The output resolution is always identical to the input

resolution

2 All output formats are always available when the format is valid for the input resolution being used

3 When only one output is required, connect that output of the SP-12HD, and leave the other outputs unconnected

4 Switch OFF the power on each device before connecting it to your SP-12HD. After connecting your SP-12HD, switch on

its power and then switch on the power on each device
