KRAMER: SIMPLE CREATIVE TECHNOLOGY

Operating the SP-12HD HD-SDI Processor

Table 3: Test Signals

TEST-4

TEST-5

TEST-6

Test Signal

1 OFF OFF OFF Normal operating mode, no test active

2 ON OFF OFF RAMP 100%

3 OFF ON OFF Y-SWEEP (5.8MHz – SDTV, 11.6MHz – EDTV, 30MHz – HDTV )

4 OFF OFF ON COLOR BARS 100%

5 ON ON OFF SPLIT BARS 100%

6 OFF ON ON PULSE 2T and BAR

7 ON OFF ON C-SWEEP (1.5MHz – SDTV, 3MHz – EDTV, 15MHz – HDTV )

8 ON ON ON GRID

7 Operating the SP-12HD HD-SDI Processor

Operate your SP-12HD via:

• The front panel buttons

• RS-232 serial commands transmitted by a touch screen system,

PC, or other serial controller

To operate the SP-12HD using the front panel buttons, do the following:

1. Turn on the power and press the INPUT button to select the source to

convert: CV, YC, YUV or SDI.

The appropriate INPUT LED lights (indicating selection of that source).

2. Press the AUTO button to select input standard that cycles as follows:

AUTO, 480i/60, 480p/60, 576i/50, 576p/50, 720p/50, 720p/59.94, 720p/60,

1080i/50, 1080i/59.94, 1080i/60, 1080p/23.98, 1080p/24, 1080p/25,

1080p/29.97, 1080p/30, 1080psf/23.98, 1080psf/24, 1080psf/25,

1080psf/29.97 and 1080psf/30.

With a CVBS or Y/C input source, the cycling sequence is reduced to three

modes: AUTO, 480i/60 and 576i/50. The appropriate 1/1.001 LED, one

SCANNING FORMAT LED, one FIELD/FRAME RATE LED and one

ACTIVE LINES PER FRAME LED lights. If the AUTO button does not

illuminate, it means a forced input standard. Otherwise, the AUTO button

illuminates, lighting LEDs to indicate the detected input standard.

3. Adjust the color, brightness, contrast, hue, sharpness

, H-shift, V-shift

• Press the appropriate button

and/or video gain of the picture, as follows:

1 Using the V-SHARP and H-SHARP buttons

The button illuminates and blinks and the 7-segment

2 Using the V-SHIFT and H-SHIFT buttons

3 See the relevant items defined in

Table 1
