Communication Protocol
17
17
Table 6: Instruction Set
#
INSTRUCTION
I5
I4
I3
I2
I1
I0
0 Reset 0 0 0 0 0 0
16 Error 0 1 0 0 0 0
32 Read front-panel switch data 1 0 0 0 0 0
33 Write front-panel switch data 1 0 0 0 0 1
34 Recall 1 0 0 0 1 0
35 Store 1 0 0 0 1 1
61 Identify machine 1 1 1 1 0 1
DESCRIPTION OF INSTRUCTIONS
Inst
No
Instruction name Data
Number
Data Name Extended Notes
0
RESET 0 Initialize machine 0 When the machine is initialized, it sends the
RESET code (DATA = 0). If the machine receives
this code, it resets to its “power-up” state.
1 Configure the
machine to its
factory default
state
0 When the machine receives this code, all
programmable parameters are reset to their factory-
default values.
16
ERROR If the machine receives an invalid instruction, it
replies by sending this error code.
32
READ FRONT
PANEL SWITCH
DATA (send)
Front panel
switch number*
0
READ FRONT
PANEL SWITCH
DATA (reply)
Front panel
switch number*
Front panel
switch value*
33
WRITE FRONT-
PANEL SWITCH
DATA
Front panel
switch number*
Front panel
switch value*
The PC sends a value directly to the machine. If
valid, the machine implements this new value, and
replies by sending the same data back to the PC.
Note that the addressed front-panel switch does not
need to be pressed in order to change its value via
RS-232.
If the “+” or “-” button is pressed on the machine,
resulting in a change in a switch value, then this
switch number and value is sent to the PC.
34
RECALL 0 0–15 Program
number
Program 0 = Setup 1 … Program 15 = Setup 16
35
STORE 0 0–15 Program
number
Program 0 = Setup 1 … Program 15 = Setup 16
61
IDENTIFY
MACHINE
3 Request software
version number
0 If the software version is requested, the machine
replies with DATA as the version number before
the decimal point, and EXTENDED DATA is the
value following the decimal point. For example, for
version 3.4, the machine replies with DATA = 03
(hex), and EXTENDED DATA = 04 (hex).
* See following table: SWITCH NUMBER AND SWITCH VALUE PARAMETERS
