The SP-12HD technical specifications are shown in Table 4:

Table 4: Technical Specifications

INPUTS:

of the SP-12HD HD-SDI Processor

1 composite video: 1Vpp/75Ω on a BNC connector;

1 Y/C: 1Vpp/75Ω (Y), 0.3Vpp/75Ω (C) on a 4-pin connector;

1 component: Y/R-Y/B-Y (1Vpp/0.7Vpp/0.7Vpp)/75Ω on BNC connectors;

1 SDI: SMPTE-259M, SMPTE-292M, SMPTE-344M, ITU-R BT.601 on a BNC

connector

OUTPUTS:

1 composite video: 1Vpp/75Ω on a BNC connector;

1 Y/C: 1Vpp/75Ω (Y), 0.3Vpp/75Ω (C) on a 4-pin connector;

1 component: Y/R-Y/B-Y (1Vpp/0.7Vpp/0.7Vpp)/75Ω on BNC connectors;

2 SDI: SMPTE-259M, SMPTE-292M, SMPTE-344M, ITU-R BT.601 on BNC

connectors

BANDWIDTH: 0.5dB to 5MHz (SDTV), to 10MHz (EDTV), to 30MHz (HDTV), fully loaded

S/N RATIO: 60dB

CONTROLS: Front-panel and RS-232: contrast, brightness, video gain, color, hue, H/V

sharpness, H/V chroma-luma shift; R-Y, B-Y level; screen splitter (process to

bypass); panel lock

INPUT VIDEO

STANDARDS:

CVBS (SDTV): PAL-B/D/G/H/I/M/N, NTSC-3.58/4.43, SECAM;

EDTV: 480p/60, 576p/50;

HDTV: 720p/50, 720p/59.94, 720p/60, 1080i/50, 1080i/59.94, 1080i/60,

1080p/23.98, 1080p/24, 1080p/25, 1080p/29.97, 1080p/30, 1080psf/23.98,

1080psf/24, 1080psf/25, 1080psf/29.97 and 1080psf/30

OUTPUT VIDEO

STANDARDS:

Same as input standard with these exceptions: for a CVBS input signal, the

output standard can be only PAL-B or NTSC-3.58 depending on input frame

rate; for EDTV or HDTV input signals, the CVBS output signal is not available

DIGITAL RESOLUTION: 10 bits

LUMA NON-LINEARITY: 1%

CHROMA / LUMA DELAY: <15ns

POWER SOURCE: Universal, 100-240V AC, 50/60Hz, 22VA max.

DIMENSIONS: 19” x 7” x 1U W, D, H, rack mountable

WEIGHT: 2.6kg (5.7lbs) approx.

ACCESSORIES: Power cord, rack “ears”, null-modem adapter
