KRAMER: SIMPLE CREATIVE TECHNOLOGY
Communication Protocol
18
SWITCH NUMBER AND SWITCH VALUE PARAMETERS
Switch Number Description Switch Value Description
0
INPUT FORMAT 0 CV (default)
1 YC
2 YUV
3 SDI
1
INPUT_STAND_YUV/SDI (for input
format YUV or SDI)
0 AUTO (default)(read D=24 for
STANDARD_AUTO)
1-480i/60 11-1080p/23.9
2-480p/60 12-1080p/24
3-576i/50 13-1080p/25
4-576p/50 14-1080p/29.9
5-720p/50 15-1080p/30
6-720p/59.9 16-1080psf/23.9
7-720p/60 17-1080psf/24
8-1080i/50 18-1080psf/25
9-1080i/59.9 19-1080psf/29.9
10-1080i/60 20-1080psf/30
2
SPLITTER -100 – +100 (2’s complement) 0 - default
3
SHARP_H 0 - 15 0 - default
4
SHARP_V 0 - 15 0 - default
5
CONTRAST -100 – +100 (2’s complement) 0 - default
6
BRIGHTNESS -100 – +100 (2’s complement) 0 - default
7
VIDEO_GAIN -100 – +100 (2’s complement) 0 - default
8
H_SHIFT -8– +7 (2’s complement) 0 - default
9
V_SHIFT -1– +1 (2’s complement) 0 - default
10
Y -100 – +100 (2’s complement) 0 - default
11
U -100 – +100 (2’s complement) 0 - default
12
V -100 – +100 (2’s complement) 0 - default
13
GREEN -100 – +100 (2’s complement) 0 - default
14
BLUE -100 – +100 (2’s complement) 0 - default
15
RED -100 – +100 (2’s complement) 0 - default
16
COLOR -100 – +100 (2’s complement) 0 - default
17
HUE -100 – +100 (2’s complement) 0 - default
18
COLOR_SPACE 0
1
2
0 – OFF default
1 – YUV
2 - RGB
19
INPUT_STAND_CV/YC_ (In case of
input format CV or YC)
0
1
2
0 - AUTO (default) (read
D=24 for
STANDARD_AUTO)
1 – NTSC
2 – PAL
20
PANEL_LOCK 0
1
Off (default)
On
21
REQUEST CURRENT SETUP 0 – 15 For I = 32 - read_only. For
recall or store use I = 34 or 35
22
FREE_COLOR 0 – 1 0 - Black_screen (default)
1 - Blue_screen
