Kramer FC-340 [15/27] Connecting the balanced unbalanced stereo audio output

FC-340 - Connecting the FC-340

6.3 Connecting the Balanced/Unbalanced Stereo Audio

Output

This section illustrates how to wire the devices to the balanced audio output:

 A balanced stereo output connection, see Figure 6

 An unbalanced stereo output connection, see Figure 7

Figure 6: Balanced Stereo Audio Connection

Figure 7: Unbalanced Stereo Audio Connection
