Kramer FC-340 [23/27] Kramer protocol
![Kramer FC-340 [23/27] Kramer protocol](/views2/1152717/page23/bg17.png)
20
FC-340 - Kramer Protocol
10 Kramer Protocol
The FC-340 supports the Kramer Protocol 3000.
The Protocol 3000 RS-232 communication protocol lets you control the machine
from any standard terminal software (for example, Windows
®
HyperTerminal
Application).
10.1 Protocol 3000 Syntax
Host message format:
Start
Address
(optional)
Body
Delimiter
#
Destination_id@
message
CR
Simple command (commands string with only one command without addressing):
start
body
delimiter
#
Command SP Parameter_1,Parameter_2,…
CR
Commands string (formal syntax with commands concatenation and addressing):
# Address@ Command_1 Parameter1_1,Parameter1_2,… |Command_2
Parameter2_1,Parameter2_2,… |Command_3 Parameter3_1,Parameter3_2,…
|…CR
Device message format:
Start
Address (optional)
Body
Delimiter
~
Sender_id@
message
CR LF
Device long response (Echoing command):
Start
Address
(optional)
Body
Delimiter
~
Sender_id@
command SP [param1 ,param2 …] result
CR LF
CR = Carriage return (ASCII 13 = 0x0D)
LF = Line feed (ASCII 10 = 0x0A)
SP = Space (ASCII 32 = 0x20)
