Kramer FC-340 [17/27] Using the menu

FC-340 - Operating the FC-340

3. Press Enter.

The Video Out options are displayed.

4. Using the up (▲) or down (▼) button, move through the Video Out options

until the flashing cursor is on Resolution.

5. Press Enter.

The Resolution options are displayed.

6. Using the up (▲) or down (▼) button, select the required output resolution.

7. Press Enter.

The selected output resolution is saved.

Note: The CV output follows the frame rate of the selected resolution. For 50Hz

resolutions the PAL standard is used, and for 59.94/60Hz resolutions NTSC is used.

7.2 Using the Menu

The menu is shown on the display when the Enter button is pressed. If there is no

button activity for approximately 30 seconds, the display reverts back to the

Input/Output display.

Navigation through the menu is performed as follows:

 Enter—display the menu or select a parameter/value

 Up (▲) or Right (►)—scroll up through the parameter/value list

 Down (▼) or Left (◄)—scroll down through the parameter/value list

 ESC—Move to the first level menu

The main menu comprises six sections:

 Video Out (see Section 7.2.1)

 Audio Out (see Section 7.2.2)

 Status (see Section 7.2.3)

 Comm Settings (see Section 7.2.4)

 System (see Section 7.2.5)
