FC-340 - Operating the FC-340
15
15
7.2.1 Video Out Sub-menu
The parameters in the Video Out sub-menu set the output video characteristics.
Parameter
Description
Options
Resolution
Sets the output
resolution
1080p59.94, 1080p60, 1080p50, NTSC, PAL,
720p59.94, 720p60, 720p50, 1080i59.94,
1080i60, 1080i50
Default—720p/59.94
Genlock
Mode
Sets the source for
the genlock signal
No Genlock, Input
Default—No Genlock
Note: The CV output frame rate follows the above settings (see Section 7.1)
7.2.2 Audio Out Sub-menu
The parameters in the Audio Out sub-menu set the audio output characteristics.
Parameter
Description
Options
Embedding >
Sets the audio group to
embed Group 1, Group
2, Group 3 and Group 4
Off, Embedded input, AES input
Default—Embedded input
AES Out 1
Embeds the AES audio
input 1
Gr1 Pair1, Gr1 Pair2, Gr2 Pair1, Gr2 Pair2,
Gr3 Pair1, Gr3 Pair2, Gr4 Pair1, Gr4 Pair2,
AES In1, AES In2, Off
Default—Gr1 Pair1
AES Out 2
Embeds the AES audio
input 2
Gr1 Pair1, Gr1 Pair2, Gr2 Pair1, Gr2 Pair2,
Gr3 Pair1, Gr3 Pair2, Gr4 Pair1, Gr4 Pair2,
AES In1, AES In2, Off
Default—Gr1 Pair2
7.2.3 Status Sub-menu
The parameters in the Status sub-menu display the input conditions.
Parameter
Description
Options
Video Input >
Displays the locked/unlocked status of
the video format and genlock
Format Unlocked
Genlock Unlocked
Audio Input
Displays the audio group status
G1 G2 G3 G4
