![Kramer FC-340 [19/27] Comm settings sub menu](/views2/1152717/page19/bg13.png)
16
FC-340 - Operating the FC-340
7.2.4 Comm Settings Sub-menu
The parameters in the Comm Settings sub-menu set the network IP and display
the serial communications values.
Parameter
Description
Options
NETWORK
IP address
Sets the IP network address
Any valid IP address
Default—192.168.001.039
IP mask
Sets the IP network mask
Any valid subnet
Default—255.255.000.000
IP gateway
Sets the IP gateway address
Any valid gateway address
Default—000.000.000.000
IP port
Sets the IP port number
Any valid TCP port
Default—05000
RS-232
Baud
Displays the baud rate
115200
Parity
Displays the parity bit setting
none
7.2.5 System Sub-menu
The parameters in the System sub-menu display the device versions and set the
LCD display characteristics.
Parameter
Description
FIRMWARE
The device firmware version
FPGA VER
The device FPGA version
S/N
The device serial number
7.3 Resetting the Device to Factory Default Configuration
To reset the device to the factory default configuration:
1. Turn the device off.
2. Press and hold the Reset button on the rear panel of the device.
3. While holding the button depressed, turn the device on.
4. Hold the button depressed for 10 seconds and release the button.
The configuration is reset to the factory default.
