Technical Specifications
18
6 Technical Specifications
Table 7 defines the technical specifications
1
:
Table 7: Technical Specifications
2
of the TP-45/TP-45RC/TP-46
VIDEO Specifications
INPUTS: TP-45/RC
1 VGA/UXGA 1Vpp/75Ω on a 15-pin HD connector
1 component 1Vpp/75Ω (YPbPr) on 3 RCA connectors
TP-46 1 twisted pair line In on an RJ-45 connector (video/audio)
OUTPUTS: TP-45/RC 1 twisted pair line Out on an RJ-45 connector (video/audio)
TP-46 1 twisted pair line Extension on an RJ-45 connector
(video/audio)
1 VGA/UXGA 1Vpp/75Ω on a 15-pin HD connector
1 component 1Vpp/75Ω (YPbPr) on 3 RCA connectors
MAX. INPUT LEVEL:
VGA: 1.2Vpp on 75Ω, DC coupling
YPbPr: 1.05Vpp on 75Ω, AC coupling
RETURN LOSS: -18dB
MAX. OUTPUT LEVEL:
VGA: 1.5Vpp on 75Ω, DC coupling
YPbPr: 1.25Vpp on 75Ω, DC coupling
VIDEO RESOLUTION: Up to UXGA; 1080p
S/N RATIO: 61dB RMS unweighted
K-FACTOR: 0.2%
ISOLATION (CROSSTALK): -43dB @ 5MHz
AUDIO Specifications
INPUTS: TP-45/RC
1 Stereo analog audio, 0dBu/50kΩ, 0.5V/75Ω, on a 3.5mm jack
1 digital S/PDIF audio on an RCA connector
OUTPUTS: TP-46
1 Stereo analog audio, 0dBu/1kΩ, 0.5V/75Ω, on a 3.5mm jack
1 digital S/PDIF audio on an RCA connector
MAX. AUDIO INPUT LEVEL ANALOG:
4dBu on 50kΩ, AC coupling
MAX. AUDIO OUTPUT LEVEL
ANALOG:
4dBu on 1kΩ, DC coupling
AUDIO BANDWIDTH: 20Hz to 20kHz, @0dBu
TND+NOISE: 0.33% @0dBu @1kHz
SAMPLE RATE CONVERSION: 48kHz
RESOLUTION CONVERSION: 24 bits
POWER SOURCE: TP-45/RC 12V DC, 140mA
TP-46: 12V DC, 280mA
DIMENSIONS: 12 cm x 7.15 cm x 2.76 cm (4.7" x 2.81" 1.09", W, D, H)
WEIGHT: 0.3 kg (0.67 lbs.) approx
ACCESSORIES: Power supply
OPTIONS: RK-3T 19" rack adapter
1 Specifications for 100m of CAT 5 UTP cable, unless otherwise specified
2 Specifications are subject to change without notice
