5 Installing the RTBUS-21

To install the RTBUS-21 perform the following steps:

1. Drill a hole in the table (see Section 5.1).

2. Insert the unit through the hole and secure the unit to the table (see

Section 5.2).

3. Connect the cables (see Section 5.3).

5.1 Drilling a Hole in the Table

To drill an opening in the table:

1. Using any standard cup bit drill with a diameter ranging from 110mm to

112mm (4.33in to 4.4in), drill a hole in the table in the desired location.

The thickness of the table should be 3in (76mm) or less.

2. Clean the table surface.

Take care not to damage the table. Kramer Electronics is not

responsible for any damage caused to the table.
