Setup Functions

Return to Factory Default

To reset the RCP to Factory Default conditions requires simultaneous button pushes to

execute the command to reset.

 Press and hold the FUNC button until it turns BLUE, while holding the FUNC

button.

 Press and hold Input Buttons 1 and 2.

 Input Buttons 1 and 2 will be BLUE. NOTE: these buttons do not light

until both are held. If either button is released, both will turn off.

 The TAKE button blinks RED.

 While continuing to hold the FUNC button and Input Buttons 1 and 2, press the

TAKE button to execute. The RCP will be reset to Factory defaults.

CAUTION!

All of your configuration changes in the RCP will be lost when you return to factory default.

If you hold down button INPUT button 1 too long after hitting the TAKE button, the front panel

may go into “Button Lamp Test” mode. All green LEDs will be on when this happens. To exit this

mode, power cycle the RCP by removing and re-applying the power.

Note:

Releasing the FUNC button will exit the Setup mode and return the panel to its previous state.

IP Address

The IP address may be viewed or changed from the front panel.

To display the IP address;

 Press and hold the FUNC button until it turns BLUE. Release the FUNC button to exit.

 Press Output Button 26 on the Aspen RCP-3232 or Output Button 10 on the Aspen RCP-

1616. This button will turn blue.

• Output buttons 1 through 4 will turn GREEN if the IP Address can be changed

from the front panel. Otherwise, these buttons will be BLUE.

 Press OUTPUT 1 button. This button will now blink.

• Three of the INPUT buttons 1 - 10 (for 0) will turn on briefly to display the 1st

octet of the IP address.

 Press OUTPUT 2 button. This button will now blink.

• Three of the INPUT buttons 1 - 10 (for 0) will turn on briefly to display the 2nd

octet of the IP address.

 Press OUTPUT 3 button. This button will now blink.

• Three of the INPUT buttons 1 - 10 (for 0) will turn on briefly to display the 3rd

octet of the IP address.

 Press OUTPUT 4 button. This button will now blink.

• Three of the INPUT buttons 1 - 10 (for 0) will turn on briefly to display the 4th

octet of the IP address.

 Release the FUNC button to exit.
