Kramer Aspen RCP-1616 [49/52] Specifications
![Kramer Aspen RCP-1616 [49/52] Specifications](/views2/1153906/page49/bg31.png)
SIERRA VIDEO
39
Specifications
Mechanical
Operating Temperature
0c – 45C
Dimensions
RCP-32323.5 (89mm) x 19.0 (483mm) x 1.25 (32 mm)
RCP-1616: 1.75 (44.5mm) x 19.0 (483mm) x 1.25 (32 mm)
Weight
RCP-3232: 2.6 lbs (1.2 kg)
RCP-1616: 1.4 lbs (0.7kg)
Electrical
AC Input Range
100-240V, 50-60Hz
Max AC Power
RCP-3232: 4.8W
RCP-1616: 3.5W
Communication
Ethernet (1)
10/100 Base-T (RJ45)
Chapter
7
