12
Yarden 8-T - Installing the Yarden 8-T
Figure 8: Adjust Tap Selector
6. Place the speaker temporarily in place, and test the audio quality.
7. If you are satisfied, disconnect the amplifier and remove the speaker from
the ceiling. If not, change the position of the tweeters and check the audio
quality again until you are happy with the results.
8. Fit the speaker grille over the speaker underside and tighten with screws.
Do not select the maximum tapping position when using 100V (in
both the stereo and mono modes).
4.5 Installing the Tile Size Speaker
1. Drop the speaker into the ceiling tile space.
Make sure that you position the speaker lengthwise relative to the room
shape (see Figure 9).
i
