Yarden 8-T - Technical Specifications
5 Technical Specifications
Audio and Power
DESCRIPTION:
Ceiling tile speaker
FREQUENCY RESPONSE:
65Hz to 20kHz @ -10dB
80Hz to 20kHz @ ±3dB
WOOFER:
8” (200mm) Kevlar(R) with rubber surround
TWEETER:
4 x 0.75” (20mm) pivoting titanium dome
IMPEDANCE:
8Ω stereo, 4Ω mono (transformer tap in off position)
TRANSFORMER TAPS:
Stereo: 70V – 3.75W/7.5W/15W/30W; 100V – 7.5W/15W/30W
Mono: 70V – 7.5W/15W/30W/60W; 100V – 15W/30W/60W
SENSITIVITY:
87dB 1W @1m
MAX SPL:
Continuous: 102dB
Peak: 105dB
POWER HANDLING:
40W RMS
110W continuous program
CROSSOVER FREQUENCY:
2.175kHz
DIRECTIVITY FACTOR (Q):
9.43, averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI)
9.5dB averaged 1kHz to 10kHz
INPUT CONNECTORS:
Terminal block connectors
CONTROLS:
Mono/Stereo select switch, Music/Speech select switch
Shipping and Installation
MATERIALS:
Frame, steel grilles (595x595mm, 600x600mm), cable holder
DIMENSIONS:
60cm x 60cm x 10cm (tile size)
59.5cm x 59.5cm x 10cm (tile size) for any region with
suspended ceiling tiles of 595mm
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
WEIGHT:
8.8 kg (19.3lbs) approx.
SHIPPING WEIGHT:
10.5 kg (27.1lbs) approx.
ACCESSORIES:
2 available grilles (595x595mm, 600x600mm)
COLORS:
Available in white
Specifications are within a 10% tolerance and are subject to change without notice at
