4343
4343
43
3.43.4
3.43.4
3.4
Advanced ScreenAdvanced Screen
Advanced ScreenAdvanced Screen
Advanced Screen
In this section, you may set the configurations for the following items: CPU
Configuration, Chipset Configuration, ACPI Configuration, Storage Configuration, PCIPnP
Configuration, SuperIO Configuration, and USB Configuration.
Setting wrong values in this section may cause
the system to malfunction.
BIOS SETUP UTILITY
Main OC Tweaker
H/W Monitor Boot Security Exit
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
Advanced Settings
WARNING:Settingwrongvaluesinbelowsections
may cause system to malfunction.
CPU Configuration
ACPI Configuration
Chipset Configuration
Storage Configuration
PCIPnP Configuration
SuperIO Configuration
USB Configuration
Options for CPU
BIOS Update Utility
Instant Flash
Instant Flash
Instant Flash is a BIOS flash utility embedded in Flash ROM. This convenient
BIOS update tool allows you to update system BIOS without entering operat-
ing systems first like MS-DOS or Windows
®
. Just launch this tool and save
the new BIOS file to your USB flash drive, floppy disk or hard drive, then you
can update your BIOS only in a few clicks without preparing an additional
floppy diskette or other complicated flash utility. Please be noted that the
USB flash drive or hard drive must use FAT32/16/12 file system. If you ex-
ecute Instant Flash utility, the utility will show the BIOS files and their respec-
tive information. Select the proper BIOS file to update your BIOS, and reboot
your system after BIOS update process completes.
