ASUS Xonar DSX
5.3.2 Connecting 2/2.1 channel speakers
No Item Description
1 Front Out/Headphone
Jack
Connect the 2/2.1 speaker set’s 3.5mm plug into this Front Out jack.
2 Speakers
2.1 Speakers
1
AUDIO
INPUTS
1
