ASUS Xonar DSX
CD Player
MP3 Player
5.5 Connecting Line-In audio sources
Line In
1
No Item Description
1 Line Input Jack Connect the 3.5mm plug of the CD/MP3 Player or any other Line level
analog audio sources into this Line-In jack for sound recording or
real-time Dolby sound processing through the Monitoring path (See
the “Mixer” section of the driver guide).
