Asus z87-plus [114/174] Chapter 3
![Asus z87-plus [114/174] Chapter 3](/views2/1159683/page114/bg72.png)
3-36
Chapter 3: BIOS setup
Chapter 3
ASM1061 Storage Controller (SATA6G_E12) [Enabled]
Allows you to select the ASM1061 storage controller operating mode.
[Disabled] Disables the ASM1061 storage controller.
[Enabled] Enables the ASM1061 storage controller.
Hot-plug [Enabled]
Allows you to set the Hot Plug support.
Conguration options: [Disabled] [Enabled]
Intel LAN Controller [Enabled]
[Enabled] Enables the Intel
®
LAN controller.
[Disabled] Disables the Intel
®
LAN controller.
Intel PXE OPROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the PXE OptionRom of the Intel
®
LAN controller.
Conguration options: [Enabled] [Disabled]
Serial Port Conguration
The sub-items in this menu allow you to set the serial port conguration.
This item only functions if there is a serial port (COM1) connector on the motherboard.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Conguration options: [Enabled] [Disabled]
Change Settings [IO=3F8h; IRQ=4]
Allows you to select an optimal setting for super I/O device.
Conguration options: [IO=3F�h; IRQ=4] [IO=2F�h; IRQ=3] [IO=3E�h; IRQ=4]
[IO=2E�h; IRQ=3]
