Asus z87-plus [14/174] Package contents
![Asus z87-plus [14/174] Package contents](/views2/1159683/page14/bge.png)
xiv
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.
• The 1 x 2-in-1 ASUS Q-Connector kit is for retailer version only.
User Manual
ASUS Z87-PLUS motherboard User manual Support DVD
3 x Serial ATA 6.0 Gb/s cables 1 x ASUS SLI™ bridge connector 1 x ASUS I/O Shield
1 x 2-in-1 ASUS Q-Connector kit
Package contents
Check your motherboard package for the following items
