4-4
Chapter 4: Software support
Chapter 4
AI Suite 3 main menu bar
• The screeshots of AI Suite 3 in this user manual are for reference only. The actualThe screeshots of AI Suite 3 in this user manual are for reference only. The actual
screenshots vary with models.
• Refer to the software manual in the support DVD or visit the ASUS website atRefer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software conguration.
System
Information
USB Charger+Ai Charger+
EZ Update
Network
iControl
Wi-Fi
Engine
USB BIOS
Flashback Wizard
Wi-Fi GO!4-Way Optimization
USB 3.0 Boost
4.3.2 Dual Intelligent Processors 4
Dual Intelligent Processors 4 comes with these ve utilities in one interface:
4-Way Optimization, TPU, EPU, DIGI+ Power Control, and Fan Xpert 2.
On some motherboard models, Dual Intelligent Processors 4 appear at AI Suite 3’s launch.
4-Way Optimization
The 4-Way Optimization utility allows you automatically tweak the TPU, EPU, DIGI + Power
Control and Fan Xpert 2 to their optimal settings.
Select an
advanced
power saving
mode
Click to auto-detect the best settings based on actual usage
DO NOT remove your fan during the tuning process.
