1.1.3 ASUS Exclusive Features
Remote GO!
ASUS Remote GO! leads the way to a more enjoyable home entertainment. With ASUS
Remote GO�, you can stream media les to DLNA devices, remotely control and access yourGO�, you can stream media les to DLNA devices, remotely control and access your
computer using your smart device.
Conveniently use and enjoy these ASUS Remote GO! functions:Remote GO! functions: GO! functions:
Cloud GO!: Allows you to control les and sync them all across cloud services in a few
clicks.
DLNA Media Hub: Provides support to the latest DLNA standard and allows you to
stream media les to a DLNA-supported device.
Remote Desktop: Allows you to view your computer’s desktop and remotely operate
your computer in real-time from your smart device.
File Transfer: Allows you to transfer les between your computer and smart device.
Download APP “Wi-Fi GO! & NFC Remote” from app store and Google Market.
GPU Boost
GPU Boost accelerates the integrated GPU for extreme graphics performance, facilitates
exible frequency adjustments and easily delivers stable system-level upgrades for every
use.
USB 3.0 Boost
ASUS USB 3.0 Boost, which supports USB 3.0 standard UASP (USB Attached SCSI
Protocol), signicantly increases a USB device’s transfer speed up to 170% faster than the
already impressive USB 3.0 transfer speed. It automatically accelerates data speeds for
compatible USB 3.0 peripherals without the need for any user interaction.
USB Charger+
With a dedicated onboard controller, quick-charge all your smart devices such as
smartphones, tablets and more, all up to three times faster, even when the system is
powered off, in sleep or hibernation mode.
USB BIOS Flashback
USB BIOS Flashback offers a hassle-free updating solution for your ultimate convenience.
Install a USB storage device containing the BIOS le, press the BIOS Flashback button for
about three seconds, and the UEFI BIOS is automatically updated even without entering
the existing BIOS or operating system. It also allows you to regularly check for UEFI BIOS
updates, and download the latest BIOS automatically.
•
•
•
•
