5-40 Chapter 5: RAID conguration
5.4.4 Preferences
System Preferences
Allow you to set to show the notication area icon and show system information, warning, or
errors here.
E-Mail Preferences
Allow you to set to sent e-mail of the following events:
• Storage system information
•
Storage system warnings
•
Storage system errors
