Asus z9pa-u8 [94/188] Me subsystem
![Asus z9pa-u8 [94/188] Me subsystem](/views2/1159825/page94/bg5e.png)
4-32 Chapter 4: BIOS setup
4.4.13 ME Subsystem
Intel ME Subsystem Conguration
ME BIOS Interface Version 1.2
ME Version 2.1.5.95
ME FW Status Value : 0xf0345
ME FW State : SPS ME FW Active
ME FW Operation State: M0 without UMA
ME FW Error Code: No Error
ME Ext FW Status value: 0x3000e301
BIOS Booting Mode: Performance Optimized
Cores Disabled: 0
ME FW SKU Information: SiEn NM
End-of-POST Status: E0P disabled in POST
ME FW Checksum: Set after ME update
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
ME Subsystem Help.
4.4.14 Onboard Devices Conguration
Serial Port 1 Conguration
Serial Port 2 Conguration
Asmedia USB 3.0 Controller [Enabled]
Asmedia USB 3.0 Battery Charging S [Enabled]
Serial Port 1/2 Conguration
Serial Port Conguration
Serial Port [Enabled]
Device Settings I0=2F8h; IRQ=3;
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Set Parameters of serial
Port 1(COM1).
Enable or Disable Serial
Port(COM).
Serial Port [Enabled]
Allows you to enable or disable the serial port.
Conguration options: [Disabled] [Enabled]
