ASUS Z9PA-U8 6-15

4. Use the USB drive to provide the third-party driver during the OS installation.

Type the command brokenmodules=ahci in Boot Options eld, and press

<Enter>.

5. When below screen appears, select the USB oppy disk drive (sda) as the

driver update medium. Select OK, then press <Enter>.

Please choose the Driver Update medium.

OK Back

sda: USB Floppy

Other device

6. Select Back and follow the onscreen instructions to nish the installation.
