Asus h81m-d plus [8/48] H81m d series specifications summary
![Asus h81m-d r2.0 [8/48] H81m d series specifications summary](/views2/1159862/page8/bg8.png)
viii
H81M-D series specications summary
Specications are subject to change without notice.
Back Panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
2 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1 x LPT port
1 x DVI port
1 x RGB port
1 x LAN (RJ-45) port
3 x Audio jacks support 8-channel audio output
Internal I/O
connectors/
buttons/switches
1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
(H81M-D Plus only)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
2 x SATA 6.0Gb/s connectors
2 x SATA 3.0Gb/s connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x COM connector
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
1 x Speaker connector
1 x System panel connector
Operating System
Support
Windows
®
8.1 / Windows
®
8 / Windows
®
7
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS
2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3, My Favorites, Quick Note, Last Modied Log, F12 PrintScreen, F3
Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Form factor
uATX form factor: 8.9 in x 7.2 in (22.6 cm x 18.3 cm)
