Asus h81m-p [13/48] Cpu heatsink and fan assembly installation
![Asus h81m-p [13/48] Cpu heatsink and fan assembly installation](/views2/1161713/page13/bgd.png)
ASUS H81M-P
1-5
2
3
A
B
C
4
5
1.3.2 CPU heatsink and fan assembly installation
ApplytheThermalInterfaceMaterial
totheCPUheatsinkandCPU
before you install the heatsink and
fan if necessary.
