ASUS H81M-P
1-17
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
SATA3G_1
GND
RSATA_TXP2
RSATA_TXN2
GND
RSATA_RXN2
RSATA_RXP2
GND
SATA3G_2
H81M-P
H81M-P SATA 3.0Gb/s connectors
8. Intel
®
H81SerialATA3.0Gb/sconnectors(7-pinSATA3G1~2[darkbrown])
TheseconnectorsconnecttoSerialATA3.0Gb/sharddiskdrivesviaSerialATA3.0
Gb/ssignalcables.
9. Intel
®
H81SerialATA6.0Gb/sconnectors(7-pinSATA6G_1~2[yellow])
TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA6.0
Gb/ssignalcables.
Whenusinghot-plugandNCQ,settheSATA Mode SelectionitemintheBIOSto[AHCI].
GND
RSATA_TXP2
RSATA_TXN2
GND
RSATA_RXN2
RSATA_RXP2
GND
SATA6G_2
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
SATA6G_1
H81M-P
H81M-P SATA 6.0Gb/s connectors
Whenusinghot-plugandNCQ,settheSATAModeSelectionitemintheBIOSto[AHCI].
