Asus h81m-p [20/48] Connectors
![Asus h81m-p [20/48] Connectors](/views2/1161713/page20/bg14.png)
1-12
Chapter 1: Product introduction
1.7 Connectors
1.7.1 Rear panel connectors
3 42
57 6
1
10
89
LAN port
Speed
LED
Activity Link
LED
LAN port LED indications
3. Line In port (light blue).Thisportconnectsthetape,CD,DVDplayer,orotheraudio
sources.
4. Line Out port (lime).Thisportconnectsaheadphoneoraspeaker.In4-channel,
6-channel,and8-channelcongurations,thefunctionofthisportbecomesFront
SpeakerOut.
5. Microphone port (pink). This port connects a microphone.
Tocongurean8-channelaudiooutput:
UseachassiswithHDaudiomoduleinthefrontpaneltosupportan8-channelaudio
output.
Activity/Link LED Speed LED
Status Description Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange(Blinking) Dataactivity GREEN 1Gbps connection
Orange(Blinking
then steady)
Readytowake
upfromS5mode
Audio2.1,4.1,5.1or7.1-channelconguration
Port
Headset
2.1-channel
4.1-channel 5.1-channel 7.1-channel
LightBlue
(Rearpanel)
LineIn RearSpeakerOut RearSpeakerOut RearSpeakerOut
Lime(Rearpanel) LineOut FrontSpeakerOut FrontSpeakerOut FrontSpeakerOut
Pink(Rearpanel) MicIn MicIn Bass/Center Bass/Center
Lime (Front panel) — — — SideSpeakerOut
1. PS/2 Mouse port (green).ThisportisforaPS/2mouse.
2. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)
throughanetworkhub.RefertothetablebelowfortheLANportLEDindications.
