1-4
Chapter 1: Product introduction
1.2.4 Layout contents
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1150socketdesignedforthe4th
Generation,New4thGenerationand5thGenerationIntel
®
Core™i7/Core™i5/Core™i3,
Pentium
®
,andCeleron
®
processors.
UnplugallpowercablesbeforeinstallingtheCPU.
Connectors/Jumpers/Slots/LED Page
1. CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN1/2) 1-15
2. ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V) 1-19
3. LGA1150CPUsocket 1-4
4. DDR3DIMMslots 1-7
5. USB3.0connector(20-1pinUSB3_12) 1-22
6. Intel
®
Z97SerialATA6.0Gb/sconnectors(7-pinSATA6G_1-6) 1-17
7. M.2Socket3 1-22
8. ClearRTCRAM(3-pinCLRTC) 1-12
9. Systempanelconnector(10-1pinPANEL) 1-21
10. Speakerconnector(4-pinSPEAKER) 1-19
11. USB2.0connectors(10-1pinUSB910,USB1112,USB1314) 1-20
12. TPMconnector(20-1pinTPM) 1-18
13. Serialportconnector(10-1pinCOM) 1-15
14. Digitalaudioconnector(4-1pinSPDIF_OUT) 1-18
15. Frontpanelaudioconnector(10-1pinAAFP) 1-16
Z97-K/USB 3.1
Z97-K/USB 3.1 CPU socket LGA1150
