CPU Middle Temperature [25]
Use the <+> or <‑> keys to set the value for CPU Middle Temperature. The range of
the values depends on the CPU installed.
CPU Fan Middle Duty Cycle(%) [20]
Use the <+> or <‑> keys to adjust the CPU fan middle duty cycle. The values range
from 20% to 100%. When the CPU temperature reaches the upper limit, the CPU fan
operates at the maximum duty cycle.
CPU Lower Temperature [20]
Use the <+> or <‑> keys to adjust the CPU fan’s lower temperature. The values range
from 20°C to 75°C.
CPU Fan Min. Duty Cycle(%) [20]
Use the <+> and <‑> keys to adjust the minimum CPU fan duty cycle. The values
range from 20% to 100%. When the CPU temperature is under the lower limit, the CPU
fan will operate at the minimum duty cycle.
2.7.5 Chassis Fan 1/2 Q-Fan Control [DC Mode]
[PWM mode] Enables the chassis Q‑Fan control in PWM mode for 4‑pin chassis fan.
[DC mode] Enables the chassis Q‑Fan control in DC mode for 3‑pin chassis fan.
[Disabled] Disables the chassis Q‑Fan control feature.
The following items appear only when you set the Chassis Fan 1/2 Q‑Fan Control to [PWM
Mode] or [DC Mode].
Chassis Fan 1/2 Q-Fan Source [CPU]
This item controls the assigned fan according to the selected temperature source.
Conguration options: [CPU] [MB]
Chassis Fan 1/2 Speed Low Limit [600 RPM]
This item allows you to disable or set the chassis fan warning speed. Conguration options:
[Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
Chassis Fan 1/2 Profile [Standard]
This item allows you to set the appropriate performance level of the chassis fan.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust depending
on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan operation.
[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set Chassis Fan 1/2 Profile to [Manual].
Chassis Fan 1/2 Upper Temperature [70]
Use the <+> or <‑> keys to adjust the upper limit of the CPU temperature. The values
range from 40°C to 75°C.
ASUS Z97-K/USB 3.1 2‑43
