Asus z97-k/usb 3.1 [62/91] Cpu graphics voltage auto

Total Adaptive Mode CPU Cache Voltage [Auto]

This item sums up the voltages of the CPU Cache Voltage offset and Additional Turbo

Mode CPU Cache Voltage options.

2.5.19 CPU Graphics Voltage [Auto]

This item allows you to set the CPU graphics voltage. Increase the graphics voltage when

increasing the iGPU frequency. Conguration options: [Auto] [Manual Mode] [Offset Mode]

[Adaptive Mode].

• The following item appears only when you set the CPU Graphics Voltage to [Manual

Mode].

• [Adaptive Mode] is available for some specic CPU types.

CPU Graphics Voltage Override [Auto]

This item allows you to set the CPU graphics voltage override. The values range from 0.001V

to 1.920V with a 0.001V interval.

The following items appear only when you set the CPU Graphics Voltage to [Offset Mode]

or [Adaptive Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Graphics Voltage Offset [Auto]

This item appears only when you set the CPU Graphics Voltage to [Offset Mode] or

[Adaptive Mode] and allows you to set the CPU graphics voltage offset. The values

range from 0.001V to 0.999V with a 0.001V interval.

The following items appear only when you set the CPU Graphics Voltage to [Adaptive

Mode].

Additional Turbo Mode CPU Graphics Voltage [Auto]

This item appears only when you set the CPU Graphics Voltage to [Adaptive Mode]

and allows you to set the additional turbo mode CPU graphics voltage. The values

range from 0.001V to 1.920V with a 0.001V interval.

Total Adaptive Mode CPU Graphics Voltage [Auto]

This item sums up the voltages of the CPU Graphics Voltage offset and Additional

Turbo Mode CPU Graphics Voltage options.

2.5.20 CPU System Agent Voltage Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

2‑28 Chapter 2: Getting started
