Front Panel Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or
high‑denition audio depending on the audio standard that the front panel audio
module supports.
[HD Audio] Sets the front panel audio connector (AAFP) mode to high denition
audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to an SPDIF audio output.
[HDMI] Sets to an HDMI audio output.
Depop [Enabled]
Conguration options: [Disabled] [Enabled]
Auto Shielding LED [Auto]
[Auto] Automatically activates the LED control based on settings of the ErP Ready
item.
[Enabled] Keeps the LED on.
[Disabled] Disables this function.
Asmedia USB 3.1 Controller [Enabled]
This item allows you to enable or disable the Asmedia USB 3.1 function.
Conguration options: [Enabled] [Disabled]
The following two items appear only when you set the Asmedia USB 3.1 Controller item to
[Enabled].
USB 3.1_1/USB3.1_2 [Enabled]
This item allows you to enable or disable USB3.1_1/USB3.1_2 controller.
Conguration options: [Enabled] [Disabled]
Asmedia USB 3.1 Battery Charging Support [Enabled]
This item allows you to enable or disable the Asmedia USB 3.1 battery charging function.
Conguration options: [Enabled] [Disabled]
Realtek LAN Controller [Enabled]
[Enabled] Enables the Realtek LAN controller.
[Disabled] Disables the controller.
Realtek PXE Option ROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to
enable or disable the PXE OptionRom of the Realtek LAN controller. Conguration options:
[Enabled] [Disabled]
ASUS Z97-K/USB 3.1 2‑39
