Asus tuf sabertooth x99 [10/186] Sabertooth x99 specifications summary
![Asus tuf sabertooth x99 [10/186] Sabertooth x99 specifications summary](/views2/1162209/page10/bga.png)
x
LAN
Dual Gigabit LAN controller - 802.3az Energy Efcient Ethernet
(EEE) appliance
Intel
®
I218-V Gigabit LAN controller - Dual interconnect between
the integrated LAN controller and physical layer (PHY)
Realtek
®
8111GR Gigabit LAN controller
Storage
New Intel
®
Core™ i7 Processors
- 1 x M.2 x4 Socket 3 with M Key, type 2242/2260/2280/22110
storage devices support (Support PCIE SSD only)
Intel
®
X99 Express Chipset with RAID 0, 1, 5, 10 and Intel Rapid
Storage Technology 13 support
- 1 x SATA Express Port (gray, compatible with 2 x SATA 6.0
Gb/s ports)
- 8 x SATA 6.0 Gb/s ports* (4 x beige/gray from controller 1, 4 x
black from controller 2)
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid
Recoverary Technology**
* Due to chipset behavior, the SATA6G_78, SATA6G_910 ports (black)
do not support IRST including RAID
** These functions will work depending on the CPU installed.
Audio
Realtek
®
ALC1150 8-channel High denition audio CODEC
- Audio shielding ensures precision analog/digital separation
and greatly reduced multi-lateral interference
- Separate layer for left and right track, ensuring both sound
deliver equal quality
- Top notch audio sensation delivers according to the audio
conguration
- Audio Amplier to enhance the highest quality sound for
headphone and speakers
- High Quality 112dB SNR stereo playback output (Line-out at
rear) and 104dB SNR recording input (Line-in) support
- Absolute pitch 192khz/24bit true BD lossless sound
- BD Audio Layer Content Protection
- Supports Jack-Detection, Multi-streaming, and Front Panel
Jack-Retasking
- Optical S/PDIF out ports at rear I/O
USB
Intel
®
X99 Express Chipset - supports ASUS USB 3.1 Boost
- 4 x USB 3.0/2.0 ports at mid-board for front panel support
- 4 x USB 3.0/2.0 ports at rear panel (blue)
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at rear
panel)
1 x ASMedia
®
USB 3.1 controller - supports ASUS USB 3.1
Boost
- 2 x USB 3.1/3.0 ports at back panel (teal blue)
(continued on the next page)
SABERTOOTH X99
specifications summary
