Asus tuf sabertooth x99 [31/186] Chapter 1
![Asus tuf sabertooth x99 [31/186] Chapter 1](/views2/1162209/page31/bg1f.png)
ASUS SABERTOOTH X99
1-15
Chapter 1
DDR4 2800 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
2 4 8
A_DATA AX4U2800W8G17-DRZ 8GB DS SK hynix H5AN4G8NMFR 17-18-
18-36
1.2V • •
A_DATA AX4U2800W4G17 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 17-17-
17-36
1.2V • •
A_DATA AX4U2800W4G17 32GB(4GB*8) SS SK hynix H5AN4G8NMFR 17-17-
17-36
1.2V • • •
A_DATA AX4U2800W8G17 32GB(8GB*4) DS SK hynix H5AN4G8NMFR 17-17-
17-36
1.2V • •
AVEXIR AVD4U28001604G-4CI 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 16-16-
16-36
1.2V • •
AVEXIR AVD4U28001504G-4BZ1 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 15-15-
15-35
1.35V • •
AVEXIR AVD4U28001608G-4CI 32GB(8GB*4) DS SK hynix H5AN4G8NMFR 16-16-
16-36
1.2V • •
AVEXIR AVD4U28001508G-4BZ1 32GB(8GB*4) DS SK hynix H5AN4G8NMFR 15-15-
15-35
1.35V • •
Apacer 78.B1GM8.AF20B 4GB SS - - 17-17-
17-36
1.2V • •
Apacer 78.C1GM8.AF30B 8GB DS - - 17-17-
17-36
1.2V • •
CORSAIR CMD16GX4M4A2800C16 16GB(4GB*4) SS - - 16-18-
18-36
1.2V • •
CORSAIR CMD32GX4M4A2800C16 32GB(8GB*4) DS - - 16-18-
18-36
1.2V • •
CORSAIR CMD64GX4M8A2800C16 64GB(8GB*8) DS - - 16-18-
18-36
1.2V • • •
CORSAIR CMD16GX4M4A2800C15 16GB(4GB*4) SS - - 15-17-
17-36
1.2V • •
CORSAIR CMD32GX4M4A2800C15 32GB(8GB*4) DS - - 15-17-
17-36
1.2V • •
CORSAIR CMK16GX4M4A2800C16 16GB(4GB*4) SS - - 16-18-
18-36
1.2V • •
CORSAIR CMK32GX4M4A2800C16 32GB(8GB*4) DS - - 16-18-
18-36
1.2V • •
CORSAIR CMK64GX4M8A2800C16 64GB(8GB*8) DS - - 16-18-
18-36
1.2V • • •
CORSAIR CMK16GX4M4A2800C15R 16GB(4GB*4) SS - - 15-17-
17-36
1.2V • •
CORSAIR CMK32GX4M4A2800C15R 32GB(8GB*4) DS - - 15-17-
17-36
1.2V • •
CORSAIR CMK16GX4M4A2800C16 16GB(4GB*4) SS Samsung K4A4G085WD 16-18-
18-36
1.2V • •
G.SKILL F4-2800C16Q-16GRR 16GB(4GB*4) SS - - 16-16-
16-36
1.2V • •
G.SKILL F4-2800C16Q-16GRB 16GB(4GB*4) SS - - 16-16-
16-36
1.2V • •
G.SKILL F4-2800C16Q-16GRK 16GB(4GB*4) SS - - 16-16-
16-36
1.2V • •
G.SKILL F4-2800C16Q-32GRR 32GB(8GB*4) DS - - 16-16-
16-36
1.2V • •
G.SKILL F4-2800C16Q-32GRB 32GB(8GB*4) DS - - 16-16-
16-36
1.2V • •
G.SKILL F4-2800C16Q-32GRK 32GB(8GB*4) DS - - 16-16-
16-36
1.2V • •
Kingston HX428C14PB2K4/16 16GB(4GB*4) SS - - 14-15-
15-40
1.35V • •
